Product Descripiton
This baby diaper production line is our pride. It shows professionalism in the raw material transportation and pretreatment stage, and ensures that raw materials meet high quality requirements through accurate transportation system and perfect pretreatment process. With the help of advanced technology, the water-absorbing core of the diaper is perfectly formed and firmly combined with other materials to ensure comfort and reliability during use. The cutting and packaging process is efficient and accurate, the quality inspection is strict, and the automatic control system optimizes the production, which is your reliable partner for producing high-quality adult diapers.
Product Info
| Product size | 25m*6m*3m(for reference only) |
| Product structure | Product structure: upper & lower tissue, cotton core (mix with SAP), cover sheet hydrophilic non-woven , ADL (Acquisitiondistribution layer) non-woven,leak guard hydrophobic non-woven back sheet,Waist band non-woven,color pattern sticker,elastic waist band, discarding sticker. |
| Control system | PLC control system,HMI Operating on the LED touch screen,Configure HDTV monitor |
| Drive system | Servo Drive(Easy to change size), timing belt and flat belt are import products, and all the key parts, are import bearings. |
| Tension system | Top tissue paper,bottom tissue paper,hydrophobic nonwoven(leg cuff),top nonwoven,ADL,back sheet,elastic nonwoven are adopt A&B
shaft active unwinding by inverter motor. |
| Safety system | It has safety device on the operating side, matched with urgent stop switch.High audio fan uses sound insulation or silencer. |
| Packaging system | according to customer requirements with palletizer machine (double push double exit ) adjustable |
| Materials corrective system | Materials corrective system: Adopt international famous brand deviation correction system |
| Power | 380V, 50HZ three phase five wire |
| Machine Capacity | 400KW (Excluding glue machine and air compressor) |
| Bleed pressure | 0.6-0.8Mpa (Air compressor needs to be prepared by customers) |
| Machine weight | 70 Tons approximately |
Features
Auto lubricating System
Auto lubricating for the cutter units ,can make the machine have better cutting effect and extend the life of cutter system | Human-Machine Interface
Working speed(piece/min), single producing output, monthly output,annual output, counting quantity and products' passing rate can show on the screen | Materials automatic feeding System
Main raw materials adopt auto unwinding, auto splicing, tension control, auto FIFE web guider functions to guarantee the precise and stablility |
Certificate
Exhibitions and partners
FAQ
1. What is your advantage of your company in hygiene machinery field?
A: We are professional company in hygiene machinery field, not only technical provide, but also we have management system, such like loading side, waste prevention side, and so on.
2. Why we choose you?
A: Our mission is, one station service, create value for you. We can help you to start business, from raw material to machinery, to management system.
3. What is your delivery date ?
A: The delivery date is 120 days after receiving the deposit, and receipt of payment.
4. What is your first order payment terms ?
A: 30% deposit in advance and 70% balance before shipment.
5. Where is your factory located? How can I visit it.
A:Our factory is based in Quanzhou city,Fujian province,China You can fly to Jinjiang air port, we will pick you up.
